Serof AS er markedsledende i Norge innen kompetanse og salg av High-Speed Kamera.

Photron FASTCAM Mini-series - High-Speed Cameras


High performance stand-alone cameras impress with compact and rugged form-factor.



Fastcam Mini CX

Mini AX100

High-G, limited space camera.

With 1080 HD resolution at 1,000 frame per second and an industry leading light sensitivity of ISO 5,000 color and ISO 10,000 monochrome, the Mini CX provides outstanding image quality.  Well suited for the space limited locations and High-G operating environments common to automotive safety testing as well as certain military/defense applications.

  • 1
  • 2
  • 3



Nyhet: Nytt Kamera.

Fastcam Mini AX200

Mini AX200

At 6,400fps full one megapixel resolution, the FASTCAM Mini AX200 is the top of the range from the Mini AX family, all providing the industry’s most light sensitive CMOS sensor with the square 20µm pixels providing ISO 12232 Ssat qualified ISO 40,000 for the monochrome versions and ISO 16,000 for the 36-bit color version.
  • 1
  • 2
  • 3



Vårt mest populære kamera.

Fastcam Mini AX100

Mini AX100 The FASTCAM Mini AX series are the industries most light sensitive high-speed cameras available anywhere. The 12-bit  FASTCAM Mini AX100 is capable of 4,000 frames per second (fps) at full 1MP resolution and 540,000 fps at reduced resolution and is available with 4GB, 8GB or 16GB of onboard capacity.
  • 1
  • 2
  • 3



Populært kamera.

Fastcam Mini AX50

Mini AX50 The FASTCAM Mini AX50 is the entry level model in the Mini AX series. Capable of 2,000 fps at megapixel resolution the Mini AX50 enjoys the industries most light sensitive CMOS high-speed sensor producing, when tested to the published ISO 12232 Ssat method, a stunning ISO 40,000  for the 12-bit monochrome and ISO 16,000 for the 36-bit color version.
  • 1
  • 2
  • 3



Populært kamera.

Fastcam Mini WX100

Mini WX100 The FASTCAM Mini WX100 provides the perfect combination of high-resolution – 4M pixel native resolution and 1080 HD (1,920 x 1,080 pixels) – in a compact and light weight package rated to withstand 100G’s shock. Available with up to 16GB on-board memory providing over 10 seconds record duration at 1080 HD resolution at 500 frames per second.
  • 1
  • 2
  • 3



1080 HD

Fastcam Mini WX50

Mini WX50 The FASTCAM Mini WX50 produces four megapixel resolution 12-bit images up to 750 frames per second (fps), full 1080 HD )1,920 by 1,080 pixels) as fast as 1,500 fps, and reduced resolution all the way up to 80,000fps. With three on-board memory options (4GB, 8GB and 16GB), the Mini WX50 is a very compact yet powerful, high-G and high definition slow motion camera.
  • 1
  • 2
  • 3



High G-impact.

Fastcam Mini UX100

Mini UX100 The FASTCAM Mini UX100 produced 1.3 megapixel (1,280 x 1,024 pixels) 12-bit images up to 4,000 frames per second (fps), 720 HD as fast as 6,400 fps, and reduced resolution all the way up to 800,000fps. With three on-board memory options (4GB, 8GB and 16GB), the UX100 is a very compact yet powerful, high-G slow motion camera.
  • 1
  • 2
  • 3



Kamera.

Fastcam Mini UX50

Mini UX50 The FASTCAM Mini UX50 produced 1.3 megapixel (1,280 x 1,024 pixels) 12-bit images up to 2,000 frames per second (fps), 720 HD as fast as 2,500 fps, and reduced resolution all the way up to 160,000fps. With three on-board memory options (4GB, 8GB and 16GB), the UX50 is a very compact yet powerful, high-G slow motion camera.
  • 1
  • 2
  • 3



Kamera.



Last ned produktbrosjyre.

Fastcam SA-Serie

Fastcam Mini-Serie

Remote Head Models
